1. The bullet will cut the infrared laser screen and the system will accurately calculate bullet position.
2. The target consists of two sets of acquisition systems. Each set of acquisition system consists of a combination of curved and linear arrays of laser emitters and 215 receivers.
3. Ring accuracy: 1/10mm (meet the International Shooting Federation Regulation 6.3.2.2).
4. Build-in LED lighting, lighting brightness ＞ 1500 lux, brightness adjustable
5. Well-designed replaceable high-power laser tube, 100,000 hours of life. Low maintenance cost.
6.Specifications 438x453x80(mm)
Weight: 10kg (include the Bullet Collector).
Stand Material: 3mm steel plate.
7. Working environment: indoor or semi-outdoor environment
Working temperature -10 °C -50 °C, relative humidity 20% -90%.
8. Power Supply System:
Model: JMD35 power supply
Input: AC100-240V
Output: DC12V, 3.0A
Power load: resistive, has overheating/overcurrent/short circuit protection.
