• The bullet will cut the infrared laser screen and the system will accurately calculate
bullet position.
• The target consists of two sets of acquisition systems. Each set of acquisition system
consists of a combination of curved and linear arrays of laser emitters and 450 receivers.
• Material: 3mm steel plate.
• Size: 600mm(L)×640mm(W)×750mm(H).
• Has a noise reduction design.
• Bullet collector stand: steel material;
size: 3600mm(L)×800mm(W)×950mm(H).
Functions:
• select the event;
• screen zoom in/zoom out;
• wipe the screen.
• Ring accuracy: 1/10mm (meet the International Shooting Federation Regulation 6.3.2.2).
• Automatically detect the working status of the main components in the bullet point
collecting system, and alarm when problems are found.
• Has automatic locking and operating temperature control functions.
• Target size: 676mm(L)×676mm(W)×80mm(H); Weight: 16kg.
Stand material: aluminum alloy; Size: 3610mm(L)×8200mm(W)×1050mm(H).
• Working environment: indoor or semi-outdoor environment;
Working temperature -10 °C -50 °C, relative humidity 20% -90%.
• Power Supply System:
Model: JMD35 power supply;
Input: AC100-240V;
Output: DC12V, 3.0A;
Power load: resistive, has overheating/overcurrent/short circuit protection.
